Navships Calibration Test Block (Inch Version) 1018 Steel

Navships Calibration Test Block (Inch Version) 1018 Steel

Price: $298.00

Part Number : NDE FLAW TECH-NAVSHIP-1071

Availability : In Stock

Description

Navships Calibration Test Block (Inch Version) 1018 Steel

Used for distance amplitude correction, sensitivity levels and flaw depth information. MTDs are engraved near both scan edges on one face. In accordance with MIL-STD-271G Figure 9, and NAVSHIPS Specification 0900-006-3010/Section 6. Also known as a "Mare Island block.

Geometry: Contains six 3/64" diameter side-drilled through-holes at distances of .25" to 2.75" in .25" increments. MTDs are engraved near both scan edges on one face.

Dimensions: 12.000" x 3.000" x 1.250".

Material: 1018 Steel
