ULTRASONIC PRACTICAL EXAM SPECIMEN INCH VERSION
ULTRASONIC PRACTICAL EXAM SPECIMEN INCH VERSION The Ultrasonic practical exam specimen contains 10 Specimens, includes 2 Plates, 1 Pipe, 1 Tee, 1 Lamination plate, 1 lamination pipe, 1 Forged Bar, 1 Casting bar, 1 Node pipe to plate, and 1 node pipe to pipe. Each specimen contains 2 “ARTIFICIAL FLAWS” Randomly placed Kit contains 10 Specimens (1) Single V Plates : 0.375” (T) x 8” (W) x 4” (L) (1) Double V Plates : 0.8” (T) x 12” (W) x 4” (L) (1) Single V Tee Plate : 0.375” (T) x 8” (W) x 4” (L) x 4” (H) (1) Single V Pipe : Ø4” Sch 80 (Wall Thickness – 0.337”) x 8” (L) (1) Lamination Plate : 6” (L) x 6” (W) x 0.6” (T). (1) Lamination Pipe : Ø6” Sch 120 (wall thickness 0.562”) x 6” (L) (1) Forged Bar Ø4” x 6” (L) (1) Casting Bar Ø4” x 6” (L) (1) Node pipe to plate – Branch pipe Ø4” sch 120 (wall thickness – 0.438”) x 6” (L) and Base plate 8” (L) x 8” (W) x 0.8” (T) (1) Node Pipe to Pipe – Branch pipe Ø4” sch 120 (wall thickness – 0.438”) x 6” (L) Base pipe Ø24” sch 60 (180°) x wall thickness 0.968” 2 Flaws in each specimen total 20 flaws Document package includes Certificate of Conformance, Drawing and Inspection Report.
ULTRASONIC PRACTICAL EXAM SPECIMEN (Metric Version)
ULTRASONIC PRACTICAL EXAM SPECIMEN (Metric Version) The Ultrasonic practical exam specimen contains 10 Specimens, includes 2 Plates, 1 Pipe, 1 Tee, 1 Lamination plate, 1 lamination pipe, 1 Forged Bar, 1 Casting bar, 1 Node pipe to plate, and 1 node pipe to pipe. Each specimen contains 2 “ARTIFICIAL FLAWS” Randomly placed Kit contains 10 Specimens (1) Single V Plates : 9.5mm (T) x 200mm (W) x 100mm (L) (1) Double V Plates : 20mm (T) x 300mm (W) x 100mm (L) (1) Single V Tee Plate : 9.5mm (T) x 200mm (W) x 100mm (L) x 100mm (H) (1) Single V Pipe : Ø114mm Sch 80 (Wall Thickness – 8.5mm) x 200mm (L) (1) Lamination Plate : 150mm (L) x 150mm (W) x 15mm (T). (1) Lamination Pipe : Ø168.3mm Sch 120 (wall thickness 14mm) x 150mm (L) (1) Forged Bar Ø100mm x 150mm (L) (1) Casting Bar Ø100mm x 150mm (L) (1) Node pipe to plate – Branch pipe Ø114 sch 120 (wall thickness – 11mm) x 150mm (L) and Base plate 200mm (L) x 200mm (W) x 20mm (T) (1) Node Pipe to Pipe – Branch pipe Ø114mm sch 120 (wall thickness – 11mm) x 150mm (L) Base pipe Ø610mm sch 60 (180°) x wall thickness 24.5mm. 2 Flaws in each specimen total 20 flaws Document package includes Certificate of Conformance, Drawing and Inspection Report.
