PAUT And TOFD Plate to Plate Single V Flawed Specimens 30mm (Metric Version) Carbon Steel
Price: $240.00
Part Number : NDE FLAW TECH-PAUT PLATE-5118
Availability : Out of Stock
Description
PAUT And TOFD Plate to Plate Single V Flawed Specimens 30mm (Metric Version) Carbon Steel
PAUT And TOFD Plate to Plate Single V Flawed Specimens ASYMMETRICAL 1/3+2/3 THK
Phased Array Ultrasonic Testing (PAUT) - Plate to Plate Single V Flawed Specimens-Time-of-flight diffraction ultrasonic
Geometry: Plate to Plate Double V Butt Weld 400mm Long and 200mm Wide on Either Side of The Weld thickness range > 20mm to 30mm Carbon Steel ASYMMETRICAL1/3+2/3 thickness.
Material: Carbon Steel.
Flaws: 3 per specimen, randomly placed Specimen Tolerance: +/- 0.080"
Documentation: NDT Verification Reports, C of C, CAD Drawings and Test Sheets.
Customized Calibration Test Block and Flaw Specimen also available.
