PAUT And TOFD Plate to Plate Single V Flawed Specimens 1.2” (Inch Version) Carbon Steel

PAUT And TOFD Plate to Plate Single V Flawed Specimens ASYMMETRICAL 1/3+2/3 THK

Phased Array Ultrasonic Testing (PAUT) - Plate to Plate Single V Flawed Specimens-Time-of-flight diffraction ultrasonic

Geometry: Plate to Plate Double V Butt Weld 16” Long and 8” Wide on Either Side of The Weld thickness range > 0.8” to 1.2” Carbon Steel ASYMMETRICAL1/3+2/3 thickness.

Material: Carbon Steel.

Flaws: 3 per specimen, randomly placed Specimen Tolerance: +/- 0.080"

Documentation: NDT Verification Reports, C of C, CAD Drawings and Test Sheets.

Customized Calibration Test Block and Flaw Specimen also available.
