DS Calibration Test Block (Metric Version) INCONEL 625

AWS-type block used for longitudinal distance and sensitivity calibration. Contains a 50.8mm high section between two 101.6mm sections. In accordance with AWS requirements. AWS and ANSI Type DS calibration Block. AWS does not specify a separate metric version of the DS block. The metric block in AWS shows only the metric equivalents to the standard design. Therefore, this one block can be used for both inch and metric requirements.

Dimensions: 152.4 mm x 101.6 mm x 50.8 mm

Material: INCONEL 625.
