5 Wedge Step Calibration Block (Metric Version) Special Alloy

Step and tapered calibration wedges come in a large variety of sizes and configurations. Step wedges are typically manufactured with four or five steps but custom wedge can be obtained with any number of steps. Tapered wedges have a constant taper over the desired thickness range. 5 Step Calibration Block for thickness and linearity calibration 5 Step Calibration Block 2.5mm to 25mm.

Dimensions: 5 Step Calibration Block has steps starting at 2.5mm to 25mm in 2.5mm, 5mm, 7.5mm, 10mm, 12.5mm increments.

Note: Customized Step Block also available.

Metric Step Face: 20mm x 20mm.

Material: Special Alloy
